- Compact coiled format
- Suitable for workshop and pneumatic routing
- Swivel BSPT termination
Metric Swivel BSPT Polyurethane Coil Assemblies
Metric red polyurethane coil assemblies with swivel BSPT terminations for coiled pneumatic assembly applications.
Blue Swivel PU Coil
| Part Number | ID | OD | Thread | Length |
|---|---|---|---|---|
| PCA0604MT14B2 | 4mm | 6mm | 1/4" | 2m |
| PCA0604MT14B4 | 4mm | 6mm | 1/4" | 4m |
| PCA1065MT14B2 | 6.5mm | 10mm | 1/4" | 2m |
| PCA1065MT14B4 | 6.5mm | 10mm | 1/4" | 4m |
| PCA1065MT14B6 | 6.5mm | 10mm | 1/4" | 6m |
| PCA1065MT14B8 | 6.5mm | 10mm | 1/4" | 8m |
| PCA1208MT38B2 | 8mm | 12mm | 3/8" | 2m |
| PCA1208MT38B4 | 8mm | 12mm | 3/8" | 4m |
| PCA1208MT38B6 | 8mm | 12mm | 3/8" | 6m |
| PCA1208MT38B8 | 8mm | 12mm | 3/8" | 8m |
Advantages
Technical Specifications
Hose Technical Specification
Metric red polyurethane coil assemblies with swivel BSPT terminations.
Hose Material: Polyurethane
Termination: Swivel BSPT
Working Limits
Working Temperature
-20°C to +100°C (NBR)
-40°C to +130°C (EPDM)
-15°C to +200°C (Viton)
Depending on Medium
